Bullfinch External Gas Point White KK6087J / 30145

Description

Features

Complete with plug in tail connector and fixing screws

Good security – no connector, no flow

Push and turn activation

Innovative, attractive design

High quality

Compact and lightweight

Easy to fit (Requires 60mm cutter)

High Flow

This version comes with angled inlet connector as shown, but for a good volume, a straight connector version can also be supplied

Nett weight with connector – 515g

Conforms to BS EN 331 and BS EN 1949 and made under a certified ISO9001 system

The Gas point comes complete with a Plug in tail connector for connecting onto the hose from the appliance. Inserting the tail connector and turning, locks it in place and allows the gas to flow.

The Gas Point comes complete with fitting instructions. It should be installed by a competent Gas Safe (was CORGI) registered installer.

It is also supplied with 4 fixing screws.

You will need a 60mm cutter to create orifice.

The metal pipe for the gas inlet needs to be 8mm.

The hose for the Plug in tail connector needs to be 8mm bore LPG hose – our number 1319. You will also need suitable hose clips.

Please note a gas cylinder should never be connected to the Gas point from the outside of the caravan or motor

Ideal for supplying

barbecues (BBQ)
cooking appliances
patio heaters and
other appliances
for LPG (propane and butane) from the unit’s existing supply.
